PRICE DETAILS MODULARS HOUSE
PREFABRICATED TIMBER FRAME BASE
- - betonyp 10 mm
- - rock wool 200 mm
- - treated wood structure 45 x 200 mm
- - vapor barrier film + waterproofing sealing strip
- - OSB 3, 22 mm
- - Autoclave-treated wood for the terrace 45 x 200 mm
A section and more details about the structure can be found on our TECHNOLOGY page.
EXTERIOR WALLS (from exterior to interior)
- - finishing coat (decorative plaster)
- - rock wool thermal insulation
- - OSB3, 12 mm for bracing
- - treated wooden frame 45 x 150 mm
- - 150 mm rock wool (2 layers: 100 mm + 50 mm)
- - vapor barrier film + waterproofing sealing strip
- - plasterboard metallic profiles
- - plasterboard 12,5 mm
U = 0,15 W/(m²K), R = 6,75 W/(m²K)
A section and more details about the structure can be found on our TECHNOLOGY page.
INTERIOR WALLS
- - plasterboard 12,5 mm
- - plasterboard metallic profiles
- - treated wooden frame 100 mm / 150 mm x 45 mm (non-self-bearing wall / self-bearing wall)
- - rock wool, 100 mm for insulation
- - plasterboard metal frame
- - plasterboard 12,5 mm, TIP H, bathroom wall
ROOF (from interior to exterior)
- - plasterboard
- - plasterboard metallic profiles
- - vapor barrier film + waterproofing sealing strip
- - rock wool 100 mm
- - wooden frame (rafters) 45 x 200 mm
- - rock wool 200 mm
- - OSB 3, 15 mm
- - anti-condensation film
- - lath and counter lath
- - click system metal sheet roof + anthracite gray rain system
U = 0,13 W/(m²K), R = 7,714 W/(m²K)
A section and more details about the structure can be found on our TECHNOLOGY page.
EXTERIOR JOINERY
- - PVC thickness 76 mm, anthracite gray (Salamander)
- - 5 U insulation chambers
- - 24 mm double glazing
- - external aluminum window sills
INTERIOR JOINERY
- - interior doors (proposed budget: 130 €/piece taxes included)
FLOOR
- - parquet - 10 €/sqm taxes included
- - floor tiles - 10 €/sqm taxes included
TERRACE AND PERGOLA
Terrace structure in treated wood, thermo-treated pine deck; pergola and parasols made of planed and sanded softwood.
ELECTRIC INSTALATION
Switchboard with automatic fuses + differential fuse, sockets, switches, lighting fixtures according to the technical sketch. Electric wall convectors for heating.
SANITARY FACILITY
Sanitary objects and fully functional sanitary installations in the bathroom.
INTERIOR DOORS
Provided, as required by the project. The ceramic tiles , parquet, interior doors, sanitary ware and lighting fixtures are provided within a predetermined budget.
ADDITIONAL OPTIONS:
- - ELECTRIC FLOOR HEATING
- - DOUBLE FLOW LOCAL MECHANICAL VENTILATION
- - TECHNICAL UNIT
THE PRICE DOES NOT INCLUDE
- - concrete foundation or concrete/mettalic pillars
- - transport, unloading
To receive a MUCH more detailed offer for the project you are interested in along with the shipping cost, fill out the form on the product page.
